Technical Data
| Guiding dimensions of running rig |
|
Length |
Diameter |
| Mainsail halyard |
25.6 m |
10 mm |
| Jib/genoa halyard |
25.6 m |
10 mm |
| Spinnaker halyard |
25.6 m |
10 mm |
| Jib sheet |
9.2 m |
12 mm |
| Genoa sheet |
9.2 m |
12 mm |
| Mainsheet |
23.0 m |
12 mm |
| Spinnaker sheet |
20.2 m |
12 mm |
| Cunningham |
2.8 m |
10 mm |
| Kickingstrap |
5.7 m |
10 mm |
| Clew-outhaul |
5.7 m |
10 mm |
| Rig |
| Rig |
Masthead |
| Mast (bridge clearance) |
12.4 m |
| Mainsail |
15.9 m2 |
| Genoa |
32.2 m2 |
| Genoa II |
25.8 m2 |
| Spinnaker |
70 m2 |
| DH-88 |
6.15 |
| LYS |
1.08 |
| Sail dimensions |
| P |
9.70 m |
| E |
2.85 m |
| T |
11.30 m |
| LP |
5.61 m |
| J |
3.53 m |
| SL |
11.30 m |
| SMW |
6.73 m |
| SPL |
3.74 m |
|
 |
